CUDY P2_EU
****
כללי
**- מק"ט: P2
**
מעבד
**- מעבד: 1.3 GHz Dual-Core, ARM Cortex-A53
**
זיכרון/ אחסון
**- Flash/ROM: 128 MB (1 Gbit) NAND
- DDR/RAM: 256 MB (2 Gbit) DDR3
**
סלולאר
**- Cellular Standards: 5G Rel. 15, DL 4G Cat. 12/ UL 4G Cat. 13
- Cellular Antennas: 4× Internal, 2× SMA Connectors for Customized Antennas
- Detachable Cellular Antennas Connector: SMA Female
- SIM Options: 1× Nano SIM Slot, eSIM (Optional for ISP Orders)
**
אלחוטיות
**- 5GHz Wi-Fi Speed: 2402 Mbps
- 2.4GHz Wi-Fi Speed: 574 Mbps
- 5GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
- 2.4GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
- Wi-Fi Antennas: Internal
- 5GHz Antenna Gain Max: 4.07 dBi
- 2.4GHz Antenna Gain Max: 3.98 dBi
- Beamforming: כן
- FEM or PA/LNA: 5GHz: 3× Internal, 2.4,GHz: 2× Internal
- Range Performance: Max: 170 m, (558 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
**
ממשקים
**- Gigabit RJ45 Ports: 2
- Ethernet Notes: 1× RJ45 port is WAN/LAN configurable, and the rest are LAN ports
- FXS Ports: 1× RJ11 (VoNR/VoLTE) (Optional)
**
ספק כוח
**- DC Input: 12V 1.5A
- Power Adapter: Input: 100 ~ 240 V, 50/60 Hz AC, Output: 12V 1.5A DC
**
עמידות
**- סביבה: Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉), Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉), Operating Humidity: 10% ~ 90% non-condensing, Storage Humidity: 5% ~ 90% non-condensing
